2 Ton Hydraulic Winch

We produce 2 Ton Hydraulic Winch more than 20 years. It features for Small volume, compact structure and high transmission efficiency. It can be applied for overhead working truck, lorry mounted crane, drill machine, mirror crane, ship equipments and so on. It is the best choice for those situations that requires the narrow space and light weight.

Send Inquiry

Product Description

It is the type of 2 Ton Hydraulic Winch widely applied for difference kinds of crane. BG series 2 Ton Hydraulic Winch are widely used in overhead working truck, lorry mounted crane, drill machine, mirror crane, ship equipments and so on. It is the best choice for those situations that requires the narrow space and light weight.


Special Features of 2 Ton Hydraulic Winch

1. Floating type planetary gearbox, smooth operation and reasonable structure.
2. Normally closed friction type brake, high braking torque, safe and reliable operating.
3. Small volume, compact structure and high transmission efficiency.
4. Long life Danfoss hydraulic orbit motor
5. Mounting frame is available on request.
6. Balance valve, shuttle valve, limit switch and other accessories are also available on request.



Model

W.L.L. 1st layer

W.L.L. top layer

Rope Speed

Rope diam.

Capacity of Rope

Working Pressure

Max Supply Oil Flow



kgf

kgf

m/min

mm

m

Mpa

L/min

BG500

500

380

63

6

67

14

40

BG800

800

680

54

8

53

14

50

BG1100

1100

870

41

8

53

14

50

BG1300

1300

1000

45

9

48

14

55

BG1500

1500

1200

42

10

60

21

55

BG2000

2000

1600

35

10

60

21

55

BG2500

2500

2000

52

12

52

21

100

BG2600

2600

2000

54

12

76

21

100

BG3200

3200

2500

44

14

66

21

100

BG3600

3600

2800

40

14

66

21

100

BG4500

4500

3500

36

15

89

21

110

BG5700

5700

4500

26

16

102

21

120

For more products about BG Series 2 Ton Hydraulic Winch, please download our catalogue or contact us!
Meanwhile, we can design and manufacture it on request.


Detail of 2 Ton Hydraulic Winch


Widely application of 2 Ton Hydraulic Winch
